3298
Classical Ogee Table Edge Bit
1/2"SH, 1"PW, 3/4"CL
Product Description
Materials: Natural woods, composite woods
Recommended RPM: 10,000-12,000 (max 12,000)
This bit has an overall design similar to a standard edge profile bit. However, the profile width is much larger for trimming the edges of a large workpiece such as a table.
- TOOL SPECS: Carbide-tipped, table edge, classical ogee bit with 1" profile width, 2-1/2" large diameter, 3/4" cutting length, 1/2" shank, 2-1/2" overall length, and B3 bearing.
- PRONOUNCED EDGE: Creates a wider, more pronounced edge profile than standard edge trimming bits.
- APPLICATIONS: Perfect for creating a classical ogee profile in a tabletop edge, adding an elegant, detailed touch to your woodworking projects.
- CARBIDE TIPPED: Offers an excellent balance of quality and cost, making it ideal for a wide range of applications.
- STEEL SHANK: The steel body creates a rigid tool with reduced vibration while the carbide cutting edges provide extended life.
- MATERIALS: Perfect for use on natural woods, hardwoods, and plastics, providing clean and precise cuts across a variety of surfaces.
Similar Sizes
| Table Edge | Part # | Profile Width | Large Dia. | Cutting Length | Overall Length |
|---|---|---|---|---|---|
| 1/2" SHANK | |||||
| Ogee | 3228 | 9/16" | 1-5/8" | 5/8" | 2-1/2" |
| Small Thumbnail | 3292 | 7/16" | 1-3/8" | 3/8" | 2" |
| Thumbnail | 3294 | 1" | 2-1/2" | 3/4" | 2-1/2" |
| Traditional | 3296 | 1" | 2-1/2" | 3/4" | 2-1/2" |
| Classical Ogee | 3298 | 1" | 2-1/2" | 3/4" | 2-1/2" |
| French Baroque | 3300 | 7/8" | 2-1/4" | 3/4" | 2-1/2" |
| Thumbnail & Bead | 3302 | 1" | 2-1/2" | 3/4" | 2-1/2" |
Bearing Number: B3
