3025
Template Bit
1/4"SH, 5/16"CD, 3/4"CL
Product Description
Materials: Natural woods, composite woods, hard plastics
Recommended RPM: 18,000-20,000 (max 24,000)
Template bits usually consist of a straight bit with a bearing. Simply align the bearing with your template and cut out your project. This specific bit includes an oversized bearing to leave a lip on your project.
- TOOL SPECS: Carbide-tipped, template bit with 5/16" cutting diameter, 3/4" cutting length, 1/4" shank, 2-3/4" overall length, 1/2" bearing diameter, and B9 bearing for use with 1/4" collets.
- TEMPLATE: Perfect for routing a pattern or shape from a template thicker than the desired final cut, allowing for precise shaping and accurate results in your woodworking projects.
- OVERHANG: Creates a subtle overhang on the edge of your workpiece, giving your project a clean, defined edge for a polished and professional finish.
- CARBIDE TIPPED: Offers an excellent balance of quality and cost, making it ideal for a wide range of applications.
- SPECIAL APPLICATIONS: Compatible with Porter Cable Morten, Mortise and Tenon Jig, and Omnijig Templates, ensuring precise, reliable performance for your woodworking projects.
- MATERIALS: Perfect for use on natural woods, composite woods, and hard plastics, providing clean and precise cuts across a variety of surfaces.
Similar Sizes
| Part # | Cutting Dia. | Cutting Length | Overall Length | Bearing Dia. | Bearing Number |
|---|---|---|---|---|---|
| 1/4" SHANK | |||||
| 1 3025 | 5/16" | 3/4" | 2-3/4" | 1/2" | B9 |
| 2 3027 | 1/2" | 1/4" | 1-7/8" | 5/8" | B6 |
| 2 3028 | 1/2" | 1/4" | 1-7/8" | 3/4" | B4 |
| 1,4 3032 | 9/16" | 3/4" | 2-1/4" | 5/8" | B6 |
1 For Porter-Cable Morten™, Mortise & Tenon Jig, and Omnijig® templates.
2 Porter-Cable Hinge Butt Mortise Bit.
3 For Hinge Mate™ II Template.
4 Keller Box Joint Bit.
